Specificaties
| Diameter | M8 |
| Producttype | Tapbout |
| DIN/ISO | DIN 933 |
| DIN/ISO norm | DIN 933 |
Toepassingen
Geschikt voor
- Staalconstructies
- Machineonderdelen
- Flensverbindingen
- Hekwerk en poorten
Niet geschikt voor
- Houtverbindingen (gebruik houtdraadbouten)
- Plaatwerk (gebruik plaatschroeven)
Tip: Een tapbout (DIN 933) heeft draad over de gehele lengte. Gebruik altijd een passende sluitring (DIN 125) en moer (DIN 934). Aandraaimoment volgens VDI 2230.
Snel leverbaar in Nederland en België via Cooltools.
| Mengstaven | |
|---|---|
| Diameter | M8 |
| Overige | |
| Schroeflengte | 10 mm of 12 mm of 14 mm of 16 mm of 18 mm of 20 mm of 22 mm of 25 mm of 30 mm of 35 mm of 40 mm of 45 mm of 50 mm of 55 mm of 60 mm of 65 mm of 70 mm of 75 mm of 80 mm of 90 mm of 100 mm of 110 mm of 120 mm of 130 mm of 140 mm of 150 mm of 160 mm of 170 mm of 180 mm of 190 mm of 200 mm |
| Lengte & verpakking | 10 mm of 12 mm of 14 mm of 16 mm of 18 mm of 20 mm of 22 mm of 25 mm of 30 mm of 35 mm of 40 mm of 45 mm of 50 mm of 55 mm of 60 mm of 65 mm of 70 mm of 75 mm of 80 mm of 90 mm of 100 mm of 110 mm of 120 mm of 130 mm of 140 mm of 150 mm of 160 mm of 170 mm of 180 mm of 190 mm of 200 mm |
| Materiaal & coating | RVS (roestvaststaal) |
| RVS-klasse | A2 (304) |
| Schroefdiameter | M8 |
| Aandrijving (bit) | Zeskant (sleutel) |
| Merk | Steelies |
| Producttype | Tapbout |
| DIN/ISO | DIN 933 |
